NEC PA552U 4K FULL HD Projeksiyon 5200 Ansi,LCD 16:9,5000:1,1920x1080
|
Projection Technology |
3LCD Technology |
|
Native Resolution |
1920 x 1200 (WUXGA) |
|
Contrast Ratio 1 |
5000:1 |
|
Brightness 1 |
5200 ANSI Lumen (approx. 80% in Eco Mode), with std. optional lense |
|
Lamp |
330 W UHP AC (264 W UHP AC Eco Mode) |
|
Lamp Life [hrs] |
3000 (4000 Eco Mode, 2000 Portrait Mode) |
|
Lens |
6 optional bayonet lenses |
|
Projection Factor |
depending on lens selection (std. option NP13ZL at 1.5-3.02:1) |
|
Projection Distance [m] |
0.7 (NP11FL) - 76.4 (NP15ZL) |
|
Screen Size (diagonal) [cm] / [inch] |
Maximum: 1,270 / 500"; Minimum: 76 / 30" |
|
Zoom |
Manual (x2 with optional lens NP13ZL) |
|
Focus Adjustment |
Manual |
|
Supported Resolutions |
4096 x 2160 (4k); 2560 x 1600 (WQXGA); 2048 x 1080 (2k); 1920x1200 (WUXGA) - 640x480 (VGA); 1080i/50/60; 1080p/24/25/30/50/60; 720p/60; 720p/50; 576i/50; 576p/50; 480p/60; 480i/50 |
|
Frequency |
Horizontal: analog: 15/24-100 kHz, digital: 15/24-153 kHz; Vertical: analog: 48-120 Hz, digital: 24-120 Hz |
CONNECTIVITY
|
RGB (analog) |
Input: 1 x 5BNC, shared with Component Signal (YPbPr); 1 x Mini D-sub 15-pin, compatible to component (YPbPr) |
|
Digital |
Input: 1 x DisplayPort; 1 x HDBaseT; 2 x HDMI™ supporting HDCP
Output: 1 x HDMI |
|
Video |
Input: 1 x BNC R Share |
|
S-Video |
Input: 1 x BNC G/B Share |
|
Audio |
Input: 1 x DisplayPort Audio support; 1 x HDBaseT audio support; 2 x 3.5 mm Stereo Mini Jack for Computer analog; 2 x HDMI audio support
Output: 1 x 3.5 mm Stereo Mini Jack (variable) |
|
Control |
Input: 1 x D-Sub 9 pin (RS-232), Ethernet |
|
USB |
1 x Type A (USB 2.0 high speed) |
|
3D Sync |
Output: 1 x Mini DIN 3pin |
|
Video Signals |
NTSC; NTSC 4.43; PAL; PAL-M; PAL-N; PAL60; SECAM |
REMOTE CONTROL
|
Input: |
1 x 3.5 mm Stereo Mini Jack |
|
Remote Control |
3D Setup; Aspect Ratio; Audio Control; Auto Adjust; DisplayPort; Eco Mode Control; Edge-Blending; Freeze-function; Geometric Correction; HDMI; Help-function; Magnify-function; Multiscreen; Page (up, down); PBP/POP Function; Picture Adjust; Picture Mute; PIP Function; Power (On-OFF); Select (up, down, left, right); Source Select; Test Picture |
ELECTRICAL
|
Power Supply |
100-240 V AC; 50 - 60 Hz |
|
Power Consumption [W] |
460 (Normal) / 362 (Eco) / 7.9 (HDBaseT Stand-by) / 0.16 (Stand-by); Sleep Mode (Lamp off): 16 |
MECHANICAL
|
Dimensions (W x H x D) [mm] |
499 x 142 x 359 (without lens and feet) |
|
Weight [kg] |
8.4 |
|
Fan Noise [dB (A)] |
33 / 39 (Eco / Normal) |
ERGONOMICS
|
Safety and Ergonomics |
CE; ErP; RoHS; TÜV GS |
|
Speakers [W] |
1 x 10 (mono) |
ADDITIONAL FEATURES
|
Special Characteristics |
4K Interface; AMX Beacon; Built-in Display/Multiscreen Splitter; Cinema Quality Picture (CQP) Processing for best image quality; Crestron RoomView; DICOM Simulation; Digital 3D Reform™; Direct Power-Off Function; Edge Blending Function (Build In); Free Tilt; Full 3DHDMI Support; Geometric Correction; HDBaseT; Keystone Correction (H=±40°, V=±40°); LAN; Lens Shift (vertical +0.5 max/-0.1 max, horizontal ± 0.3 max.); Manual Wall Color Correction; Multi-Screen compensation mode; NaViSet Administrator 2; Optional User Logo; OSD with 27 languages; Password Security System; PIP/Side by Side, HDMI - Input; PJ LINK; Portrait Setting; RS-232 Control; Stacking Function; Timer-Function; Virtual Remote for direct PC control |
GREEN FEATURES
|
Energy Efficiency |
Intelligent Power Management; Less than 0.16W Stand-By power |
|
Ecological Materials |
100% recyclable packaging; Downloadable manuals; Unique NEC NeCycle Bio-Plastic cable cover option |
|
Ecological Standards |
ErP compliant |
WARRANTY
|
Projectors |
3 years pan-European service |
|
Light Source |
6 months, max. 1000 hrs |
SHIPPING CONTENT
|
Shipping Contents |
IR Remote Control (RD - 466E); Network Set-up Guide; Power Cord; Projector; Quick Setup Guide; Users Manual on CD-ROM |
OPTIONAL ACCESSORIES
|
Optional Accessories |
Cable Cover (NP04CV); Lamp (NP26LP) |
|
Lenses |
NP11FL (0.8:1); NP12ZL (1.19-1.56:1); NP13ZL (1.5-3.02:1); NP14ZL (2.97-4.79:1); NP15ZL (4.7-7.2:1); NP30ZL (0.79-1.03:1) |
