| Technology |
Three-chip DLP® projector with APOC optical color processing and user-selectable optical color space (sRGB, REC709 or optionally DCI). Individual color filters are available for R, G, and B channels for optimum color accuracy and full flexibility. |
| Concept |
Three-chip, powered lens shift system with user adjustable optical colour processing filters. |
| 3D capability |
Active Stereo |
| Resolution |
1080p (1,920 x 1,080), WUXGA (1,920 x 1,200) |
| Brightness |
Up to 11,000 lumens (user-configurable through lamp power and voice coil operated IRIS adjustment) |
| Contrast |
Up to 15,000 : 1 (Fixed user-adjustable through voice coil operated IRIS F2-6 - 7.0 or user activated adapative dynamic IRIS feature) |
| Aspect ratio |
16:9 (1080p), 16:10 (WUXGA) |
| Display colors |
30-bit RGB |
| Latency |
~19 ms |
| Computer graphics formats |
2,560 x 1,600 - 640 x 480 pixel resolution / RGBHV, RGBS, RGsB / custom formats available |
| Horizontal scan frequencies |
10 - 150kHz |
| Vertical scan frequencies |
48 – 190 HZ (resolution dependant) |
| Video formats |
EDTV (576p, 480p), SDTV (576i, 480i), HDTV (1080p, 1080i, 720p), NTSC, PAL, SECAM |
| Lens operation |
Motorized zoom, focus, shift, iris and mechanical shutter |
| Lenses |
- Standard projection lens EN21
- Ultra Wide Angle lens EN22 lens
- Wide Angle Zoom EN23 lens
- Short Tele Zoom EN24 lens
- Long Tele Zoom EN23 lens
|
| Image width |
2 - 10 m |
| Light source |
400W UHP replacement lamp 1 / 400W UHP replacement lamp 2 |
| Lamp lifetime |
Up to 1,500 hours (full power) / Up to 2,000 hours (eco mode) |
| Computer inputs |
2 x DVI-D, 2 x HDMI 1.3a, 2 x VGA, 1 x 5-BNC |
| Video Input |
1 x HDMI 1.3a, 1 x YPbPr, 1 x S-video, 1 x Composite |
| Control possibilities |
1 x RJ-45 TCP/IP, 1 x 9-pin D-SUB RS232, 1 x USB, 2 x 12V programmable trigger (3.5mm mini jack) |
| Dimensions |
604 x 250 x 462 mm (WxHxD) |
| Weight |
24.1 kg |
| Shipping Dimensions |
820 x 420 x 720 mm (WxHxD) |
| Shipping Weight from Factory |
32 kg |
| Power requirements |
100-240 V / 207 - 264 VAC, 50-60 Hz / Max 1,080 W / 4.7 A @ 230 V, 4.7 A @ 240 V, 11.3A @ 100V |
| Conformances |
CE, FCC Class A, UL and cUL |
| Operating temperature |
10 - 40 °C |
| Storage temperature |
-20 - 60 °C |
| Altitude |
Up to 3,000 m |
| Color |
Soft touch rubber matte black |
| Warranty |
3 years, 500 hours or 90 days on lamp (whichever comes first). Up to 5 years total warranty available. Conditions apply. |
| MTBF |
24,184 hours |
| BTU per hour |
<3,520 |
