The RDM communicator is a tool box for remote setting of Robe and Anolis fixtures via DMX link. Its main purpose is to set fixture options (DMX address, DMX mode...etc) for Anolis non-display fixtures like ArcPad Xtreme, ArcPad 48 Integral but can be used with any Robe or Anolis fixtures which support RDM protocol.
Main features
-
Setting user options and reading fixture information of any Robe fixture with RDM protocol
-
Possibility to set multiple fixtures on DMX line
-
Graphic touch screen
-
4 operational buttons
-
Battery operated
Suported functions
-
DMX address setting
-
DMX mode selecting
-
Pan/tilt setting
-
Fixture display setting
-
Fixture reset
-
Fixture identification
-
Readouts (device hours,lamp hours, lamp strikes, software version,device label )
-
Lamp on/off
-
No extra PSU needed (only for charging the battery)
-
Rugged aluminium housing
-
3-pin/5-pin XLR input
-
Dimensions (h x w x d): 53mm x 98mm x 152mm
-
Weight: 0.4kg
