Technical Summary
Amplifier Power
2 x 120 W @ 4 Ω, 2 x 100 W @ 70/100 V
Signal-to-Noise Ratio
75 dB (below rated power, A-weighted)
THD
≤0.5 % (at full rated power)
Dynamic Range
80 dB
Input Channels
6 channels
Output Channels
2 channels
Applications
-
Conference centers
-
Retail stores
-
Restaurants and bars
-
Hotels
-
Lobbies and conference rooms
Key Features
-
Six inputs: four mic/line inputs with choice of balanced Euroblock or unbalanced RCA connectors, one page input and one direct input
-
Two powered outputs that can operate at high or low impedance: 2 x 120 W at 4 ohms , 2 x 65 W at 8 ohms, or 2 x 100 W at 70/100V
-
Three operating modes for greater flexibility in installed music or speech applications: Mixer Mode, Dual Mono Select Mode, and Stereo Select Mode
-
Easy setup and control via onboard controls – no computer needed
-
DSP includes loudspeaker EQs and dynamic EQ functions engineered specifically for Bose loudspeakers
-
Opti-voice® paging provides a smooth transition between music and announcements
-
24-volt DC backup power connection for added reliability and integration onto fire and evacuation systems
Physical
Dimensions
3.5" H x 16.5" W x 13.8" D (90 mm x 420 mm x 349 mm)
Net Weight
32 lb (14.4 kg)
