Can distribute a maximum of 4, 8, 16 or 32 audio channels
Can be used with DCN Next Generation, or analogue systems like the CCS 900
Flexible configuration of channels and channel quality modes for efficient distribution
Configuration of transmitter and system via a display and one single rotary push button
Mains voltage 100-240 Vac, 50-60 Hz
Power consumption
operating, maximum 55 W
standby 29 W
Asymmetrical audio inputs +3 dBV nominal, +6 dBV maximum (± 6 dB)+15 dBV nominal, +18 dBV maximum (± 6 dB)
Symmetrical audio inputs +6 to +18 dBV nominal
Emergency switch connector Emergency control input
Headphone output 32 ohm to 2 kohm
HF input Nominal 1 Vpp, minimum 10 mVpp, 75 ohm
HF output 1 Vpp, 6 VDC, 75 ohm
Dimensions (H x W x D)
for tabletop use, with feet 92 x 440 x 410 mm(3.6 x 17.3 x 16.1 in)
for 19” rack use, with brackets 88 x 483 x 410 mm(3.5 x 19 x 16.1 in)
in front of brackets 40 mm (1.6 in)
behind brackets 370 mm (14.6 in)
