Designed according to international standards, the SDC 8200 ID interpreter unit is an ideal choice for large, international conferences with up to 28 translated languages and up to eight interpreter units per booth. The SDC 8200 ID is extremely easy to use. All important information and settings are shown on a back-lit graphic LCD display. The incoming languages can be chosen via three configurable relais keys. A language quality indicator marks the language which has been translated several times, thus avoiding possible information loss.
Features
-
Gooseneck microphone with red LED ring
-
Two 3.5 mm headphone jacks
-
3,5 mm jack input for head set microphone
-
Three tone controls for volume, mid-range and treble
-
Built-in high-quality loudspeaker (automatically muted when a microphone in the booth is switched on)
-
Loudspeaker volume control
-
Loudspeaker channel selection for incoming language
-
Three configurable relais keys for incoming languages
-
Two A and B output channels, channel selection key and "ENGAGED" LEDs
-
Configurable B channel
-
Back-lit graphic LCD display for relay languages, quality of relay languages, loudspeaker language, set-up mode (only during basic configuration)
-
Large, red MIC key with LED
-
Mute key
-
Message keys with LED for displaying text messages
| Color |
black |
| Dimensions |
150 x 80 x 185 mm |
| Frequency response |
100.....14000 Hz |
| Weight |
640 g |
| Power consumption |
max. 3,5 W |
| Microphone connector |
3,5 mm stereo |
| Pick-up pattern |
cardioid |
| Operating temperature |
+5.....+50 °C |
| Goose neck length |
380 mm |
| Headphone connector |
3.5 mm mono (>32 Ohm) |
| Input voltage range |
typ. 6,3 mV |
| Housing |
ABS |
| Input impedance |
≥ 1 kOhm (1kHz) |
| Standards |
ISO 2603; IEC 849 |
| Voltage |
48 V DC |
