| Brightness |
- Dual lamp: 14,000 centre (12,500 ANSI, 14,062 ISO) lumens
- Single lamp: 7,000 centre (6,250 ANSI, 6,812 ISO) lumens
|
| Contrast |
- 2,500:1 (full on/off) 650:1 ANSI (typical)
|
| Uniformity |
- 90% brightness uniformity
|
| Display type |
|
| Resolution |
|
| Lamp type |
|
| Lamp life |
- High power: 1,750 hrs @ 450W
- Low power: 2,000 hrs @ 360W
|
| Standard inputs |
- Twin DisplayPort input card
- Dual-link DVI
|
| Optional inputs |
- Dual-link DVI
- Dual 3G SD/HD-SDI
- Video decoder
- Twin HDMI
- Analog (5 BNC)
|
| Input signals |
- HDTV formats VGA through to QXGA (2048 x 1536)
- Accepts all current HDTV/DTV formats
- Multi-standard video decoder
- Horizontal and vertical scaling, all inputs
|
| Pixel clock |
|
| Scan rates |
- Horizontal: 15 to 120 kHz
- Vertical: 23.97 to 150 Hz
|
| Inputs, control & networking |
- RS232 in/out
- RS422 in
- Ethernet (10/100)
- USB device
- GPIO (RS232 9-pin male connector)
- Built-in backlit LCD keypad
- Remote control (with optional wired XLR connection)
|
| Optical systems |
- Dust sealed, 3-chip DMD light engine
- Motorized horizontal and vertical lens offset
- Scheimpflug (tilt) adjustment
- Built-in light shutter
- Tool-free lens insertion system
|
| Fixed lenses |
- ILS lens 0.73:1 SX+/0.67:1 HD*
- ILS lens 1.2:1 SX+/1.1:1 HD
|
| Zoom lenses |
- ILS lens 1.25-1.6:1 SX+/1.16-1.49:1 HD**
- ILS lens 1.5-2.0:1 SX+/1.4-1.8:1 HD
- ILS lens 2.0-2.8:1 SX+/1.8-2.6:1 HD
- ILS lens 2.8-4.5:1 SX+/2.6-4.1:1 HD
- ILS lens 4.5-7.3:1 SX+/4.1-6.9:1 HD
- ILS lens 7.3-11.2:1 SX+/6.9-10.4:1 HD
|
| Offsets |
- ±112% Vertical
- ±54% Horizontal
- (* ±22%V / ±6%H)
- (** ±82%V / ±38%H)
|
| Standard accessories |
|
| Optional accessories |
- Coarse dust filter
- Fog juice filter
- Ceiling mount
- Ceiling mount extension
- ILS lens adapter kit
- Stacking frame
- Christie AutoStack™
- DMX512 interface card
|
| Enhanced feature sets |
- LiteLOC™
- Comprehensive Colour Adjustment (CCA™)
- Embedded Christie Twist™ image warping and edge-blending
- Intelligent Lens System (ILS™) for zoom, focus, horizontal and vertical offset for all lenses
- Auto setup
- Digital keystone correction
- Menus in five languages
- 99 channel memories
- Multi-windowing and processing (up to a 3 x 3 array)
- Black level blending
- 3D upgradable
|
| Operating voltage |
|
| Operating current |
|
| Power |
|
| Dissipation |
|
| Size |
- (LxWxH): 22.1 x 19.7 x 10.2" (561 x 500 x 259mm)
|
| Shipping dimensions |
- (LxWxH): 29.0 x 27.0 x 24.6" (737 x 689 x 625mm)
|
| Weight |
- 55 lbs (25kg) (without lens)
|
| Shipping weight |
|
| Operating environment |
- Temperature: 40 to 104° F (5 to 40° C)
- Humidity: 20-80% non-condensing
|
