SPECIFICATIONS |
KW122 |
KW152 |
KW153 |
|
Configuration |
12" 2-way multipurpose |
15" 2-way trapezoidal |
15" 3-way trapezoidal |
Transducers
Low-frequency
Mid-frequency
High-frequency |
12" cone transducer
-
1.75" diaphragm compression driver |
15" cone transducer
-
1.75" diaphragm compression driver |
15" cone transducer
6.5" mid range cone transducer
1.75" diaphragm compression driver |
|
Frequency Response (-6 dB) |
53 Hz - 18 kHz |
47 Hz - 18 kHz |
35 Hz - 18 kHz |
|
Frequency Range (-10 dB) |
50 Hz - 20 kHz |
44 Hz - 20 kHz |
33 Hz - 20 kHz |
|
Nominal Coverage (-6 dB) |
75° axisymmetric |
60° axisymmetric |
75° axisymmetric |
|
Maximum SPL1 |
131 dB peak |
133 dB peak |
134 dB peak |
|
Amplifier |
|
Power Output2 |
1000 W Class D (500 W LF, 500 W HF) continuous
2000 W peak |
1000 W Class D (500 W LF, 500 W MF/HF) continuous
2000 W peak |
|
Input Impedance (ohms) |
Channel A XLR / ¼":
|
Mic gain setting |
Balanced |
Unbalanced |
|
0 dB |
38k |
19k |
|
+12 dB |
10k |
5k |
|
+24 dB |
2.66k |
1.33k |
|
+36 dB |
660 ohms |
330 ohms |
Channel B XLR / ¼": 38k balanced / 19k unbalanced
Channel B RCA: 10k |
|
Controls |
Power, Gain A, Gain B, Channel A Input Gain (0 dB / 12 dB / 24 dB / 36 dB), LF Mode (Ext Sub/Norm/DEEP™), HF Mode (Flat/Vocal Boost), Front LED (On/Off/Limit) |
|
Indicators |
Power, Signal A, Signal B, Standby, Limit, Mic (24 dB and 36 dB settings) |
|
Connectors |
Balanced female XLR/¼" line/mic level input, Balanced female XLR/¼" line level input, Dual Balanced male XLR full range line level out , Balanced male XLR "mix" out, Stereo RCA line level input, Remote gain control, Locking IEC power connector |
|
Cooling |
On demand, 50 mm variable speed fan |
|
Amplifier Protection |
Thermal limiting, output overcurrent, overtemperature muting, GuardRail™ |
|
Transducer Protection |
Thermal limiting, excursion limiting |
|
AC Power Input |
Universal power supply 100-240 VAC, 50 - 60 Hz |
AC Power Consumption
(1/8 Power) |
100 VAC, 2.3 A
120 VAC, 2.01 A
230 VAC, 1.13 A |
|
Enclosure |
|
Material |
15 mm painted birch plywood |
|
Finish |
Black textured paint |
|
Grille |
Black powder coated 16 gauge steel |
|
Dimensions (HWD) |
26" x 15" x 15.4"
660 mm x 381 mm x 391 mm |
32.1" x 17.5" x 15.2"
816 mm x 445 mm x 386 mm |
43.1" x 18.5" x 16.8"
1094 mm x 470 mm x 427 mm |
|
Weight (Net) |
49 lb (22.2 kg) |
64 lb (29 kg) |
87 lb (39.5 kg) |
|
Available Accessories |
KW SUS KIT 122, KW122 COVER, KW M10 KIT |
KW152 COVER, KW M10 KIT |
KW153 COVER, KW M10 KIT |
